On-Stage

Passive USB DI Box

Model: DB2150
UPC: 659814133116
Automatically configured by Windows and macOS for easy, plug-and-play use
Connects via USB for compatibility with a wide range of computers
Transformer isolation eliminates noise caused by ground loops

Customers who bought this product also purchased

Product Properties

  • Application
  • Computers, mp3 players, projectors, and DJ equipment
  • Bullet points
  • Automatically configured by Windows and macOS for easy, plug-and-play use
    Connects via USB for compatibility with a wide range of computers
    Transformer isolation eliminates noise caused by ground loops
  • Construction
  • Metal w/ nylon bumpers
  • Dimensions
  • 5.75" x 3.5" x 1.5"
  • Dynamic Range
  • 90dB
  • Frequency Response
  • 10Hz - 20kHz
  • Ground lift
  • Yes
  • Input
  • USB 2.0 type C
  • Iso Switch
  • Yes
  • Mono Sum
  • Yes
  • Output
  • XLR (stereo), 3.5mm headphone
  • Output Impedance
  • 200 Ohms
  • Sample Rate
  • 96k
  • Weight
  • 0.70 lb

Description:

Our DB2150 Stereo USB DI Box converts digital audio to discrete stereo analog XLR signals ready to send via long cable runs to a mixer or PA system. For convenient plug-and-play use with laptops, when connected via USB C, Windows and Mac computer operating systems automatically recognize this box as an available soundcard. Features include low-distortion passive circuitry, monitoring via a 3.5 mm headphone output, a ground-lift switch to eliminate ground-loop hum, transformer isolation switches for defeating channel-specific ground-loop hum, and a mono-sum switch to convert a stereo source to a mono output. Its heavy-duty metal enclosure protects the internal components and ensures reliable performance.
